mysql 기반의 리플리케이션 및 mmm 설치
MYSQL 설치
-
설치환경 구성1. Mysql사용자정보 추가
[root@localhost ~]# groupadd –g 1002 mysql [root@localhost ~]# useradd -M mysql -u 1002 –g 1002 -d /svc/mysql/
- 추가 패키지 설치
[root@localhost ~]# yum install ncurses* openssl-devel* \ gdbm-devel* curl* gmp* libxml2* libtermcap* cmake* libc-client-devel\ libcurl-devel libxslt -y
- 바이너리&환경설정 설치패키지&환경설정 다운로드
[root@localhost ~]# tar -zxf mysql-5.6.34-linux-glibc2.5-x86_64.tar.gz [root@localhost ~]# mv mysql-5.6.34-linux-glibc2.5-x86_64 /svc/mysql [root@localhost ~]# mv -f my.cnf /etc/my.cnf [root@localhost ~]# cp /svc/mysql/ [root@localhost ~]# ./scripts/mysql_install_db --user=mysql --datadir=/svc/db_data/ [root@localhost ~]# chown -R root: /svc/mysql/ [root@localhost ~]# chown -R mysql: /svc/db_data/ [root@localhost ~]# cp support-files/mysql.server /etc/init.d/mysqld [root@localhost ~]# chmod +x /etc/init.d/mysqld
- 서비스 등록 및 실행
[root@localhost ~]# /etc/init.d/mysqld start Starting mysqld: [ OK ]
- 추가 패키지 설치
-
MYSQL 이중화 구성1. 서버 ID설정 (Active/Standby 모두 설정)
[root@localhost ~]# vi /etc/my.cnf … server-id = 1 (Active는 1, Standby는 2로 설정)
- 리플리케이션 권한 설정서버 리플리케이션 설정 (Active/Standby 모두 설정)
mysql> grant replication slave on . to 'repl'@'상대방DB_IP' identified by 'repl'; mysql> flush privileges; Query OK, 0 rows affected (0.00 sec)
- 액티브 서버에서 수행
mysql> show master status \G; 1. row *************************** File: binlog.000004 Position: 722 Binlog_Do_DB: Binlog_Ignore_DB: Executed_Gtid_Set: 1 row in set (0.00 sec) ERROR: No query specified
- 스탠바이서버에서 수행
mysql> change master to master_host='상대방DB_IP', master_user='repl', master_password='repl', master_log_file='binlog.000004', master_log_pos=722; Query OK, 0 rows affected, 2 warnings (0.02 sec)
- 리플리케이션 연동 (각 DB서버에서 수행)
mysql> start slave; Query OK, 0 rows affected (0.00 sec)
- Standby 시작 및 상태 확인 (Active/Standby 모두 설정)
mysql> show slave status \G; *************************** 1. row *************************** Slave_IO_State: Waiting for master to send event Master_Host: 상대방DB_IP Master_User: repl Master_Port: 3306 Connect_Retry: 60 Master_Log_File: binlog.000004 Read_Master_Log_Pos: 722 Relay_Log_File: relay-bin.000007 Relay_Log_Pos: 280 Relay_Master_Log_File: binlog.000005 Slave_IO_Running: Yes Slave_SQL_Running: Yes Replicate_Do_DB: Replicate_Ignore_DB: Replicate_Do_Table: Replicate_Ignore_Table: Replicate_Wild_Do_Table: Replicate_Wild_Ignore_Table: Last_Errno: 0 Last_Error: Skip_Counter: 0 Exec_Master_Log_Pos: 120 Relay_Log_Space: 607 Until_Condition: None Until_Log_File: Until_Log_Pos: 0 Master_SSL_Allowed: No Master_SSL_CA_File: Master_SSL_CA_Path: Master_SSL_Cert: Master_SSL_Cipher: Master_SSL_Key: Seconds_Behind_Master: 0 Master_SSL_Verify_Server_Cert: No Last_IO_Errno: 0 Last_IO_Error: Last_SQL_Errno: 0 Last_SQL_Error: Replicate_Ignore_Server_Ids: Master_Server_Id: 1 Master_UUID: 2667fd34-0483-11e7-b59d-525400a0f91d Master_Info_File: /svc/db_data/master.info SQL_Delay: 0 SQL_Remaining_Delay: NULL Slave_SQL_Running_State: Slave has read all relay log; waiting for the slave I/O thread to update it Master_Retry_Count: 86400 Master_Bind: Last_IO_Error_Timestamp: Last_SQL_Error_Timestamp: Master_SSL_Crl: Master_SSL_Crlpath: Retrieved_Gtid_Set: Executed_Gtid_Set: Auto_Position: 0 1 row in set (0.00 sec) ERROR: No query specified
- 리플리케이션 권한 설정서버 리플리케이션 설정 (Active/Standby 모두 설정)
Mysql-MMM 설치하기
- Mysql-MMM구성도
- MMM(Multi-Master Replication Manager for MySQL)은 리플리케이션으로 DB데이터를 이중화했을때, 각 DBMS별로 상태 확인하여 ReadWrite, Readonly VIP를 관리하기 위한 오픈소스
- 서버별 설치 Component
대상서버
Component
역 할
svcdb/dashboard_db Mysql, mmm-agent Mysql, 데이터 동기화, mmm 상태확인 db monitor mmm-monitor 각 Agent별 Healthcheck, VIP 관리 - MMM접근 설정 (DB서버)
mysql> grant process,super,replication client on . to 'agent'@'자신IP' identified by 'agent'; Query OK, 0 rows affected (0.00 sec) mysql> flush privileges; Query OK, 0 rows affected (0.00 sec)
- MMM-agent 설치 (DB서버)모니터 접근 허용하기 (DB서버)
mysql> GRANT REPLICATION CLIENT ON . TO 'monitor'@'MONITOR서버IP' IDENTIFIED BY 'monitor'; 1 row in set (0.00 sec) mysql> flush privileges; Query OK, 0 rows affected (0.00 sec)
MMM agent 설치
- 설치에 필요한 패키지
- mysql-mmm-2.2.1-2.el6.noarch.rpm
- mysql-mmm-agent-2.2.1-2.el6.noarch.rpm
- mysql-mmm-tools-2.2.1-2.el6.noarch.rpm
OS환경에 따라 종속된 패키지가 필요할 수 있음. 종속된 패키지는 perl관련 패키지가 설치되어 있어야 함.
- mmm-agent설치
[root@localhost ~]# yum install –y mysql-mmm-2.2.1-2.el6.noarch.rpm [root@localhost ~]# yum install –y mysql-mmm-agent-2.2.1-2.el6.noarch.rpm [root@localhost ~]# yum install –y mysql-mmm-tools-2.2.1-2.el6.noarch.rpm
- mmm-common.conf 설정
$> vi /etc/mysql-mmm/mmm_common.conf active_master_role writer <host default> cluster_interface bond0 #서버NIC 인터페이스 기재 pid_path /var/run/mysql-mmm/mmm_agentd.pid bin_path /usr/libexec/mysql-mmm/ replication_user repl #리플리케이션 사용자 입력 replication_password repl #리플리케이션 사용자 패스워드 agent_user agent #mmm을 통해 DBMS로 접근할 사용자 입력 agent_password agentpass #패스워드 입력 </host> <host db1> ip Mater 서버IP mode master peer db2 </host> <host db2> ip Standby 서버IP mode master peer db1 </host> <role writer> hosts db1, db2 ips DB VIP mode exclusive </role>
- mmm - mmm_agent.conf 설정
$> vi /etc/mysql-mmm/mmm_agent.conf include mmm_common.conf # The 'this' variable refers to this server. Proper operation requires # that 'this' server (db1 by default), as well as all other servers, have the # proper IP addresses set in mmm_common.conf. this db1 # Active는 db1, Standby는 db2로 기재
- mmm-agent 서비스 실행 후 프로세스 상태 확인
[root@localhost ~]# /etc/init.d/mysql-mmm-agent start Starting mmm_agentd: [ OK ] [root@localhost ~]# ps -ef | grep mmm root 8052 8031 0 10:12 pts/0 00:00:00 grep mmm root 18251 1 0 2016 ? 00:00:00 mmm_agentd root 18253 18251 0 2016 ? 04:03:18 mmm_agentd
MMM-monitor 설치 (Satistics#2 서버)
- 설치에 필요한 패키지
- mysql-mmm-2.2.1-2.el6.noarch.rpm
- mysql-mmm-monitor-2.2.1-2.el6.noarch.rpm
- mysql-mmm-tools-2.2.1-2.el6.noarch.rpm
OS환경에 따라 종속된 패키지가 필요할 수 있음. 종속된 패키지는 perl관련 패키지가 설치되어 있어야 함.
- svcdb용 MMM 설정
$> vi /etc/mysql-mmm/mmm_common_svcdb.conf active_master_role writer <host default> cluster_interface bond0 서버NIC 인터페이스 기재 pid_path /var/run/mysql-mmm/mmm_agentd_svcdb.pid bin_path /usr/libexec/mysql-mmm/ replication_user repl 리플리케이션 사용자 입력 replication_password repl 리플리케이션 사용자 패스워드 agent_user agent mmm을 통해 DBMS로 접근할 사용자 입력 agent_password agentpass 패스워드 입력 </host> <host db1> ip svcdb Mater 서버IP mode master peer db2 </host> <host db2> ip svcdb Standby 서버IP mode master peer db1 </host> <role writer> hosts db1, db2 ips svcdb VIP mode exclusive </role> $> vi /etc/mysql-mmm/mmm_mon_svcdb.conf include mmm_common_svcdb.conf <monitor> ip 127.0.0.1 pid_path /var/run/mysql-mmm/mmm_mond_svcdb.pid bin_path /usr/libexec/mysql-mmm status_path /var/lib/mysql-mmm/mmm_mond_svcdb.status ping_ips svcdb RIP IP는 콤마(,)로 구분 auto_set_online 60 port 9991 </monitor> <host default> monitor_user mmm_monitor mmm 접근 사용자 monitor_password monitorpw mmm 패스워드정보 </host> debug 0 $> vi /etc/mysql-mmm/mmm_mon_log_svcdb.conf log4perl.logger = INFO, MMMLog log4perl.appender.MMMLog = Log::Log4perl::Appender::File log4perl.appender.MMMLog.Threshold = INFO log4perl.appender.MMMLog.filename = /var/log/mysql-mmm/mmm_mond_svcdb.log log4perl.appender.MMMLog.recreate = 1 log4perl.appender.MMMLog.layout = PatternLayout log4perl.appender.MMMLog.layout.ConversionPattern = %d %5p %m%n
-
서비스 등록
- init.d스크립트 복사
[root@localhost ~]# cp /etc/init.d/mysql-mmm-monitor /etc/init.d/mysql-mmm-svcdb
- 스크립트 수정
$> vi /etc/init.d/mysql-mmm-svcdb #!/bin/sh # # mysql-mmm-monitor This shell script takes care of starting and stopping # the mmm monitoring daemon. # # chkconfig: - 64 36 # description: MMM Monitor. # processname: mmm_mond # config: /etc/mysql-mmm/mmm_mon.conf # pidfile: /var/run/mysql-mmm/mmm_mond.pid # Source function library and defaults file. . /etc/rc.d/init.d/functions . /etc/default/mysql-mmm-monitor # Cluster name (it can be empty for default cases) CLUSTER='svcdb' LOCKFILE='/var/lock/subsys/mysql-mmm-monitor' prog='MMM Monitor Daemon' if [ "$CLUSTER" != "" ]; then MMMD_MON_BIN="/usr/sbin/mmm_mond @$CLUSTER" MMMD_MON_PIDFILE="/var/run/mysql-mmm/mmm_mond_$CLUSTER.pid" else MMMD_MON_BIN="/usr/sbin/mmm_mond" MMMD_MON_PIDFILE="/var/run/mysql-mmm/mmm_mond.pid" Fi
- init.d스크립트 복사
-
dashboard_db MMM설정
$> vi /etc/mysql-mmm/mmm_common_dashboard_db.conf active_master_role writer <host default> cluster_interface bond0 서버NIC 인터페이스 기재 pid_path /var/run/mysql-mmm/mmm_agentd-cssatdb.pid bin_path /usr/libexec/mysql-mmm/ replication_user repl 리플리케이션 사용자 입력 replication_password repl 리플리케이션 사용자 패스워드 agent_user agent mmm을 통해 DBMS로 접근할 사용자 입력 agent_password agentpass 패스워드 입력 </host> <host db1> ip dashboard_db Mater 서버IP mode master peer db2 </host> <host db2> ip dashboard_db Standby 서버IP mode master peer db1 </host> <role writer> hosts db1, db2 ips dashboard_db VIP mode exclusive </role> $> vi /etc/mysql-mmm/mmm_mon_dashboard_db.conf include mmm_common_dashboard_db.conf <monitor> ip 127.0.0.1 pid_path /var/run/mysql-mmm/mmm_mond_dashboard_db.pid bin_path /usr/libexec/mysql-mmm status_path /var/lib/mysql-mmm/mmm_mond_dashboard_db.status ping_ips dashboard_db RIP입력 IP는 콤마(,)로 구분 auto_set_online 60 port 9990 </monitor> <host default> monitor_user mmm_monitor mmm 접근 사용자 monitor_password monitorpw mmm 패스워드정보 </host> debug 0 $> vi /etc/mysql-mmm/mmm_mon_log_dashboard_db.conf log4perl.logger = INFO, MMMLog log4perl.appender.MMMLog = Log::Log4perl::Appender::File log4perl.appender.MMMLog.Threshold = INFO log4perl.appender.MMMLog.filename = /var/log/mysql-mmm/mmm_mond_dashboard_db.log log4perl.appender.MMMLog.recreate = 1 log4perl.appender.MMMLog.layout = PatternLayout log4perl.appender.MMMLog.layout.ConversionPattern = %d %5p %m%n
- 서비스 등록
- init.d스크립트 복사
[root@localhost ~]# cp /etc/init.d/mysql-mmm-monitor /etc/init.d/mysql-mmm-dashboard_db
- init.d스크립트 내용변경
%> vi /etc/init.d/mysql-mmm-dashboard_db #!/bin/sh mysql-mmm-monitor This shell script takes care of starting and stopping the mmm monitoring daemon. chkconfig: - 64 36 description: MMM Monitor. processname: mmm_mond config: /etc/mysql-mmm/mmm_mon.conf pidfile: /var/run/mysql-mmm/mmm_mond.pid Source function library and defaults file. . /etc/rc.d/init.d/functions . /etc/default/mysql-mmm-monitor Cluster name (it can be empty for default cases) CLUSTER='dashboard_db' LOCKFILE='/var/lock/subsys/mysql-mmm-monitor' prog='MMM Monitor Daemon' if [ "$CLUSTER" != "" ]; then MMMD_MON_BIN="/usr/sbin/mmm_mond @$CLUSTER" MMMD_MON_PIDFILE="/var/run/mysql-mmm/mmm_mond_$CLUSTER.pid" else MMMD_MON_BIN="/usr/sbin/mmm_mond" MMMD_MON_PIDFILE="/var/run/mysql-mmm/mmm_mond.pid" fi
- Centos7 환경에서MMM-monitor등록
- systemctl 서비스 생성 및 등록
[root@localhost ~]# cd /usr/lib/systemd/system [root@localhost system]# cp mysql-mmm-monitor.service mysql-mmm-monitor_svcdb.service [root@localhost system]# cp mysql-mmm-monitor.service mysql-mmm-monitor_dashboard_db.service [root@localhost system]# systemctl enable mysql-mmm-monitor_svcdb.service [root@localhost system]# systemctl enable mysql-mmm-monitor_dashboard_db.service $> vi /usr/lib/systemd/system/ mysql-mmm-monitor_svcdb.service [Unit] Description=MySQL MMM Monitor After=network.target mysqld.service [Service] Type=forking PIDFile=/var/run/mmm_mond_svcdb.pid ExecStart=/etc/init.d/mysql-mmm-monitor-svcdb start ExecStop=/etc/init.d/mysql-mmm-monitor-svcdb stop PrivateTmp=true [Install] WantedBy=multi-user.target $> vi /usr/lib/systemd/system/ mysql-mmm-monitor_dashboard_db.service [Unit] Description=MySQL MMM Monitor After=network.target mysqld.service [Service] Type=forking PIDFile=/var/run/mmm_mond_svcdb.pid ExecStart=/etc/init.d/mysql-mmm-monitor-dashboard_db start ExecStop=/etc/init.d/mysql-mmm-monitor-dashboard_db stop PrivateTmp=true [Install] WantedBy=multi-user.target
-
서비스 실행
- MMM-monitor 서비스 실행 (monitor서버에서 실행)
[root@localhost ~]# /etc/init.d/mysql-mmm-svcdb start Starting mmm_mond: [ OK ] [root@localhost ~]# /etc/init.d/mysql-mmm-dashboard_db start Starting mmm_mond: [ OK ]
- Mysql 프로세스 실행 상태 확인서비스 상태 확인 (db서버에서 실행)
[root@localhost ~]# ps –ef | grep mysql root 6714 1 0 Jan08 ? 00:00:00 /bin/sh /usr/local/mysql/bin/mysqld_safe --datadir=/home/mysqldata --pid-file=/home/mysqldata/localhost.pid mysql 7856 6714 0 Jan08 ? 00:26:50 /usr/local/mysql/bin/mysqld --basedir=/usr/local/mysql --datadir=/home/mysqldata --plugin-dir=/usr/local/mysql/lib/plugin --user=mysql --log-error=/home/mysqldata/error.log --open-files-limit=8192 --pid-file=/home/mysqldata/localhost.pid --socket=/tmp/mysql.sock --port=3306
- Mysql 쿼리 처리여부 확인
[root@localhost ~]# mysql -u root -p'root패스워드' -e'select now()' 2017-03-12 19:06:14
- Mmm 프로세스상태 확인
[root@localhost ~]# ps -ef | grep mmm root 10832 1 0 Mar07 ? 00:00:00 mmm_mond-dashboard_db root 10834 10832 0 Mar07 ? 00:04:27 mmm_mond-dashboard_db root 10843 10834 0 Mar07 ? 00:01:49 perl /usr/libexec/mysql-mmm/monitor/checker @dashboard_db ping_ip root 10846 10834 0 Mar07 ? 00:01:03 perl /usr/libexec/mysql-mmm/monitor/checker @dashboard_db mysql root 10848 10834 0 Mar07 ? 00:00:35 perl /usr/libexec/mysql-mmm/monitor/checker @dashboard_db ping root 10850 10834 0 Mar07 ? 00:01:29 perl /usr/libexec/mysql-mmm/monitor/checker @dashboard_db rep_backlog root 10852 10834 0 Mar07 ? 00:01:28 perl /usr/libexec/mysql-mmm/monitor/checker @dashboard_db rep_threads root 10960 1 0 Mar07 ? 00:00:00 mmm_mond-svcdb root 10962 10960 0 Mar07 ? 00:04:23 mmm_mond-svcdb root 10969 10962 0 Mar07 ? 00:01:47 perl /usr/libexec/mysql-mmm/monitor/checker @svcdb ping_ip root 10972 10962 0 Mar07 ? 00:01:03 perl /usr/libexec/mysql-mmm/monitor/checker @svcdb mysql root 10974 10962 0 Mar07 ? 00:00:35 perl /usr/libexec/mysql-mmm/monitor/checker @svcdb ping root 10976 10962 0 Mar07 ? 00:01:27 perl /usr/libexec/mysql-mmm/monitor/checker @svcdb rep_backlog root 10978 10962 0 Mar07 ? 00:01:27 perl /usr/libexec/mysql-mmm/monitor/checker @svcdb rep_threads root 29560 27996 0 21:40 pts/3 00:00:00 grep mmm
- MMM 이중화 상태 확인 (dashboard_db)
[root@localhost ~]# mmm_control @dashboard_db show db1(192.168.67.230) master/ONLINE. Roles: writer(192.168.67.229) db2(192.168.67.231) master/ONLINE. Roles:
- MMM 이중화 상태 확인 (svcdb)
[root@localhost ~]# mmm_control @svcdb show db1(192.168.67.224) master/ONLINE. Roles: writer(192.168.67.223) db2(192.168.67.225) master/ONLINE. Roles:
- DBMS별 상태 확인 (svcdb)
[root@localhost ~]# mmm_control @svcdb checks all db2 ping [last change: 2017/03/09 11:03:42] OK db2 mysql [last change: 2017/03/09 11:03:42] OK db2 rep_threads [last change: 2017/03/09 11:03:42] OK db2 rep_backlog [last change: 2017/03/09 06:02:35] OK: Backlog is null db1 ping [last change: 2017/03/09 11:03:42] OK db1 mysql [last change: 2017/03/09 11:03:42] OK db1 rep_threads [last change: 2017/03/09 11:03:42] OK db1 rep_backlog [last change: 2017/03/09 11:03:42] OK: Backlog is null
- DBMS별 상태 확인 (dashboard_db)
[root@localhost ~]# mmm_control @dashboard_db checks all db2 ping [last change: 2017/03/09 10:58:37] OK db2 mysql [last change: 2017/03/09 10:58:37] OK db2 rep_threads [last change: 2017/03/09 10:58:37] OK db2 rep_backlog [last change: 2017/03/09 10:58:37] OK: Backlog is null db1 ping [last change: 2017/03/09 10:58:37] OK db1 mysql [last change: 2017/03/09 10:58:37] OK db1 rep_threads [last change: 2017/03/09 10:58:37] OK db1 rep_backlog [last change: 2017/03/09 10:58:37] OK: Backlog is null
- MMM-monitor 서비스 실행 (monitor서버에서 실행)
FAQ
- 설치 과정의 오류
현상 rpm설치시 아래내용으로 메시지 출력후 설치 실패
[root@localhost ~]# rpm -Uvh 123.rpm
warning: 123.rpm: Header V3 RSA/SHA256 Signature, key ID 0608b895: NOKEY
error: Failed dependencies:
perl(Log::Log4perl) is needed by mysql-mmm-2.2.1-2.el6.noarch원인 MMM 설치시 종속된 패키지 설치 실패 확인사항 perl-Proc-Daemon, perl-Proc-ProcessTable, perl-Log, perl-Mail 패키시 설치여부 확인 조치방안 관련된 전체 패키지 내려받은 후 설치작업 수행 - MMM-monitor 서비스 구동 실패현상
현상 설치 및 설정완료후 서비스 구동시 구동불가
[root@localhost ~]# /etc/init.d/mysql-mmm-dashboard_db-monitor start
Starting MMM Monitor Daemon: Configuration file /etc/mysql-mmm/mmm_mon_dashboard_db.conf is world readable! at
/usr/share/perl5/vendor_perl/MMM/Common/Config.pm line 132 [실패]원인 Mmm config의 권한 설정의 오류 확인사항 /etc/mysql-mmm/ 경로에 있는 config파일의 퍼미션 확인 조치방안 전체 퍼미션을 640으로 설정 수행
Chmod 640 /etc/mysql-mmm/*.conf - VIP할당 실패
현상 Mmm 서비스 구동 후 IP할당불가 원인 monitor에서 mysql로 접근하는 권한이 오류가 있어 mysql상태체크 불가 확인사항 /var/log/mysql-mmm/mmm-agent.log에서 Can't connect to MySQL sever 문자열 존재여부 확인 조치방안 Mysql 접근권한 설정 - MMM 리소스 확인시 중복출력
현상 mmm_config를 통해 DBMS별 상태 확인 불가 원인 Group별 생성되는 포트를 생성하지 않는 경우 발생 확인사항 /etc/mysql-mmm/mmm_mon_svcdb.conf, /etc/mysql-mmm/mmm_mon_svcdb.conf 파일안에 port항목이 기재되어 있고, 각각 다른 포트를 사용하는지 확인 조치방안 dbms별 포트 설정 - Centos7에서 mmm_monitor cluster 구성실패
현상 Systemctl을 이용한 mysql-monitor 서비스 작동 실패 원인 Systemctl을 이용한 mmm-monitor실행은 cluster모드를 지원하지 않음 확인사항 Systemctl 구문안에 ExecStart / ExecStop 구문의 명령어 확인
/etc/init.d/mysql-mmm-monitor- 파일이 있는지 확인조치방안 설정파일 및 서비스 구동 명령어 확인
