Centos에서 puppet 설치하기

back

구성정보

  1. Master machine
  2. ip : 192.168.10.10 / master.localdomain / Centos6
  3. Agent machine
  4. ip : 192.168.10.100 / agent.localdomain / Centos6

공통작업

  1. 리포지터리 추가
    $> rpm -Uvh http:/yum.puppetlabs.com/puppetlabs-release-el-6.noarch.rpm
Retrieving http:/yum.puppetlabs.com/puppetlabs-release-el-6.noarch.rpm
warning: /var/tmp/rpm-tmp.Ze6mXg: Header V4 RSA/SHA1 Signature, key ID 4bd6ec30: NOKEY
Preparing...                ########################################### [100%]
       package puppetlabs-release-6-11.noarch is already installed

서버 구성하기

  1. 마스터서버 작업하기
  2. 패키지 설치
    $> yum install puppet-server -y
===============================================================================================
Package                Arch         Version                   Repository                 Size
===============================================================================================
Installing:
puppet-server          noarch       3.8.2-1.el6               puppetlabs-products        24 k
Installing for dependencies:
augeas-libs            x86_64       1.0.0-10.el6              base                      314 k
compat-readline5       x86_64       5.2-17.1.el6              base                      130 k
facter                 x86_64       1:2.4.4-1.el6             puppetlabs-products        99 k
hiera                  noarch       1.3.4-1.el6               puppetlabs-products        23 k
libselinux-ruby        x86_64       2.0.94-5.8.el6            base                      100 k
puppet                 noarch       3.8.2-1.el6               puppetlabs-products       1.6 M
ruby                   x86_64       1.8.7.374-4.el6_6         base                      538 k
ruby-augeas            x86_64       0.4.1-3.el6               puppetlabs-deps            21 k
ruby-irb               x86_64       1.8.7.374-4.el6_6         base                      317 k
ruby-libs              x86_64       1.8.7.374-4.el6_6         base                      1.7 M
ruby-rdoc              x86_64       1.8.7.374-4.el6_6         base                      381 k
ruby-shadow            x86_64       1:2.2.0-2.el6             puppetlabs-deps            13 k
rubygem-json           x86_64       1.5.5-3.el6               puppetlabs-deps           763 k
rubygems               noarch       1.3.7-5.el6               base                      207 k

Transaction Summary
===============================================================================================
Install      15 Package(s)
  3. config 수정하기
    $> vi /etc/puppet/puppet.conf
[main]
   # The Puppet log directory.
   # The default value is '$vardir/log'.
   logdir = /var/log/puppet

   # Where Puppet PID files are kept.
   # The default value is '$vardir/run'.
   rundir = /var/run/puppet

   # Where SSL certificates are kept.
   # The default value is '$confdir/ssl'.
   ssldir = $vardir/ssl
   moduledir = /etc/puppet/modules

[agent]
   # The file in which puppetd stores a list of the classes
   # associated with the retrieved configuratiion.  Can be loaded in
   # the separate ``puppet`` executable using the ``--loadclasses``
   # option.
   # The default value is '$confdir/classes.txt'.
   classfile = $vardir/classes.txt

   # Where puppetd caches the local configuration.  An
   # extension indicating the cache format is added automatically.
   # The default value is '$confdir/localconfig'.
   localconfig = $vardir/localconfig

[master]
  certname = master.localdomain
moduledir 경로추가, certname = master.localdomain에 master호스트네임 기재
  4. 패키지 업그레이드
    $> puppet resource package puppet-server ensure=latest
package { 'puppet-server':
 ensure => '3.8.2-1.el6',
}
  5. 서비스 시작
    $> /etc/init.d/puppetmaster start
Starting puppetmaster:                                     [  OK  ]

  6. 포트상태 확인

    $>  netstat -antp | grep LISTEN
tcp        0      0 0.0.0.0:8140                0.0.0.0:*                   LISTEN      1127/ruby
tcp        0      0 0.0.0.0:22                  0.0.0.0:*                   LISTEN      878/sshd
tcp        0      0 127.0.0.1:25                0.0.0.0:*                   LISTEN      897/sendmail
tcp        0      0 :::22                       :::*                        LISTEN      878/sshd
* tcp/8140번 포트가 오픈되어 있는지 확인.

  7. Agent 작업하기

  8. 패키지 설치
    $>  yum install puppet -y
===============================================================================================
Package                Arch         Version                   Repository                 Size
===============================================================================================
Installing:
 puppet                 noarch       3.8.2-1.el6               puppetlabs-products       1.6 M
Installing for dependencies:
 augeas-libs            x86_64       1.0.0-10.el6              base                      314 k
 compat-readline5       x86_64       5.2-17.1.el6              base                      130 k
 facter                 x86_64       1:2.4.4-1.el6             puppetlabs-products        99 k
 hiera                  noarch       1.3.4-1.el6               puppetlabs-products        23 k
 libselinux-ruby        x86_64       2.0.94-5.8.el6            base                      100 k
 ruby                   x86_64       1.8.7.374-4.el6_6         base                      538 k
 ruby-augeas            x86_64       0.4.1-3.el6               puppetlabs-deps            21 k
 ruby-irb               x86_64       1.8.7.374-4.el6_6         base                      317 k
 ruby-libs              x86_64       1.8.7.374-4.el6_6         base                      1.7 M
 ruby-rdoc              x86_64       1.8.7.374-4.el6_6         base                      381 k
 ruby-shadow            x86_64       1:2.2.0-2.el6             puppetlabs-deps            13 k
 rubygem-json           x86_64       1.5.5-3.el6               puppetlabs-deps           763 k
 rubygems               noarch       1.3.7-5.el6               base                      207 k

Transaction Summary
===============================================================================================
Install      14 Package(s)
  9. 설정파일 수정
     $> vi /etc/puppet/puppet.conf
 ...
 [agent]
 certname=agent.localdomain
 runinterval = 60
 certname = 에이전트 호스트네임 추가, runinterval은 업데이트 주기(초단위)로 설정하면 됨.
 ...
$>  vi /etc/sysconfig/puppet
...
PUPPET_SERVER에 마스터 서버 호스트네임 입력
PUPPET_LOG에 에이전트 로그파일 파일명 입력
  10. 서비스 시작
    $>  /etc/init.d/puppet start
Starting puppet agent:                                     [  OK  ]
$>  ps -ef | grep puppet
root      1072     1  3 16:03 ?        00:00:00 /usr/bin/ruby /usr/bin/puppet agent --server=master.localdomain --logdest=/var/log/puppet/puppet.log
* 프로세스 실핵확인하면 됨

서버 연동하기

  1. 마스터서버에서 인증작업하기
  2. 인증이 필요한 클라이언트 확인
    $>  puppet cert --sign --list
"agent.localdomain" (SHA256) 52:0D:EF:51:BB:50:99:FE:BC:6D:2F:33:CC:A9:43:73:3B:1C:C6:A1:D6:4C:D2:13:DE:AA:75:E9:7E:D2:2A:E5
* 도메인 옆에 +기호가 붙어있으면 인증이 완료된 에이전트 입니다.
  3. 에이전트 인증작업 수행
    $>  puppet cert --sign agent.localdomain
Notice: Signed certificate request for agent.localdomain
Notice: Removing file Puppet::SSL::CertificateRequest agent.localdomain at '/var/lib/puppet/ssl/ca/requests/agent.localdomain.pem'
  4. 인증완료여부 확인
    $>  puppet cert --sign --all --list
+ "agent.localdomain"  (SHA256) 9C:18:CA:26:73:CA:65:96:85:07:B1:F4:B7:A3:2C:43:FA:EE:63:3C:A7:A3:6C:CD:A2:51:5B:81:D2:E5:2D:3F
도메인 옆에 +기호가 생기면 완료.
    • 연동이 잘 되었는지 테스트.
  5. 아래 경로에서 파일생성
    $> cat /etc/puppet/manifests/site.pp
file {
'/tmp/hello' :
 owner => root,
 group => root,
 mode => 444,
 content => "Hello Pupplet
by Machine\n";
}
    • /tmp/hello 파일이 생성되는데, 생성시 root의 사용자와 그룹으로 지정하여 생성하고 퍼미션은 444(read)생성하되, 텍스트 데이터는 Hello Pupplet라는 데이터로 저장
  6. pupplet 적용하기
    $>  puppet apply  /etc/puppet/manifests/site.pp
Notice: Compiled catalog for master in environment production in 0.17 seconds
Notice: /Stage[main]/Main/File[/tmp/hello]/content: content changed '{md5}723c9d4525cebf11f4e6171740b15abd' to '{md5}7b1d27a85c9ebf03075ee2150fb4d770'
Notice: Finished catalog run in 0.09 seconds
에이전트)
/tmp/hello파일이 생성되었는지 확인
  7. Agent 작업하기
    $>  ls -l /tmp/hello
-r--r--r-- 1 root root 25 Sep 14 16:11 /tmp/hello
$>  cat /tmp/hello
Hello Pupplet
by Machine

  8. /tmp/hello파일이 생성되었는지 확인

  9. https:/docs.puppetlabs.com/guides/install_puppet/install_el.html?_ga=1.81661140.2146970350.1440482857/

  10. http:/ora-sysdba.tistory.com/entry/Infra-%EC%84%9C%EB%B2%84%EA%B4%80%EB%A6%AC%EC%9D%98-%ED%9A%A8%EC%9C%A8%ED%99%94-Puppet-%EC%84%A4%EC%B9%98/
